SMART CLASSix (CAT 6)

CABLES

R3729070 - CLASSix UTP Horizontal Cable, HFFR, 500m Reel

R3729071 - CLASSix UTP Horizontal Cable, HFFR, 1000m Reel

R3729072 - CLASSix UTP Horizontal Cable, HFFR, 305m Box

Datasheet

R3729170 - CLASSix UTP Horizontal Cable, PVC, 500m Reel

R3729171 - CLASSix UTP Horizontal Cable, PVC, 1000m Reel

R3729172 - CLASSix UTP Horizontal Cable, PVC, 305m Box

Datasheet

CLASSix UTP Horizontal Cable - Israel

100-ohm, flexible, horizontal UTP cable
Four twisted pairs
High performance, designed for ATM 622 Mbps and Gigabit Ethernet 1000 Mbps applications
Specified up to 250 MHz
Conforms to ANSI/TIA/EIA-568-B.2-1, ISO/IEC 11801 2nd edition (2002) and CENELEC EN50173 (2002) for Category 6/Class E
Two options: Halogen-free, flame-retardant (HFFR) or PVC jacket
Available in easy-pull, ready-to-use box

R3720172 - Cat6, UTP, Horizontal Cable, 23 AWG, PVC, Grey, 305m Box

Datasheet

R3720072 - Cat6, UTP, Horizontal Cable, 23 AWG, LSZH, Grey, 305m

Datasheet

R3720772 - Cat6, UTP, Horizontal Cable, 23 AWG, LSZH, Blue, 305m Box

Datasheet

R3720672 - Cat6, UTP, Horizontal Cable, 23 AWG, PVC, Blue, 305m Box

Datasheet

R3719072 - CAT6 UTP, Horizontal Cable, AWG23, LSZH, 332-3-22, 305m Box

Datasheet

CLASSix UTP Horizontal Cable - International

Enhanced performance cable for transmission of high speed data, digital and analogue voice and video (RGB) signals on LANs.
Supports Gigabit Ethernet (1000 Base-T) standard.
Operates at bandwidth of 250MHz.
This cable well exceeds the requirements of ANSI/TIA-568-C.2, ISO/IEC 11801:2010 (Ed. 2.2) and ISO/IEC 61156-5
Two options: LSZH or PVC jacket

R3720035 - CAT6 SF/UTP, Data Cable, 23 AWG, LSZH, Gray, 305m Reel
Datasheet

CLASSix (Cat 6) 23AWG SF/UTP LSZH Cable

Designed to support Cat 6 Link and Channel performance
Electrical performance up to 250 MHz
Reduced electromagnetic radiation with the use of Al-foil, braiding and drain wire
ANSI/TIA-568-C.2
ISO/IEC 11801 Ed. 2.0
Flammability Rating: IEC 60332-1
PH and Toxicity Index: IEC 60754-1&2
Smoke Density Index IEC 61034-2
RoHS2: Directives 2011/65/EU, 2015/863/EU

R3620050 - CAT6, UTP, Solid Cable, AWG23, Double Jacket LSZH/PE, Black, 305m Reel

Datasheet

CLASSix UTP 23 AWG, LSZH/PE Double Jacket Cable

Operates at bandwidth of 250 MHz
Supports PoE Type 4 applications (IEEE 802.3bt)
Exceeds the requirements of ANSI/TIA-568-C.2, ISO/IEC 11801:2010
23 AWG Cable with HDPE Jacket
Double Jacket Cable with Inner Jacket as LSZH
Anti-Rodent Cable

R3722872 - CAT6, UTP, Horizontal Cable, AWG24, LSZH, 305m Box
Datasheet

CLASSix UTP 24 AWG LSZH Horizontal Cable

Indoor use
4 shielded twisted pairs are cabled and jacketed with a LSZH compound
Gigabit Ethernet 10/100/1000Base-T
Power over Ethernet

R3722972 - CAT6, UTP, Horizontal Cable, AWG24, PVC, 305m Box
Datasheet

CLASSix UTP 24 AWG PVC Horizontal Cable

Indoor use
4 shielded twisted pairs are cabled and jacketed with a PVC compound
Gigabit Ethernet 10/100/1000Base-T
Power over Ethernet

R3726000 - CLASSix STP Horizontal Cable, HFFR, 500m Reel

R3726001 - CLASSix STP Horizontal Cable, HFFR, 1000m Reel

R3726100 - CLASSix STP Horizontal Cable, PVC, 500m Reel

R3726101 - CLASSix STP Horizontal Cable, PVC, 1000m Reel

Datasheet

CLASSix STP Horizontal Cable

100 ohm, foiled and shielded horizontal cable
Four individually foiled twisted pairs with an overall braid-shield
High performance, designed for ATM 622 Mbps and Gigabit
Ethernet 1,000 Mbps applications
Specified up to 250 MHz
Conform to ANSI/TIA/EIA-568-B.2-1, ISO/IEC 11801 2nd edition (2002) and CENELEC EN50173 (2002) for Category 6/Class E
Halogen-free, flame-retardant (HFFR) or PVC jacket

R3729060 - CLASSix U/FTP Horizontal Cable, HFFR, 500m Reel

Datasheet

R3729160 - CLASSix U/FTP Horizontal Cable, PVC, 500m Reel

Datasheet

CLASSix U/FTP Horizontal Cable

100 ohm, U/FTP horizontal cable
Four individually foiled twisted pairs
High performance, designed for ATM 622 Mbps and Gigabit Ethernet 1000 Mbps applications
Specified up to 250 MHz
Conforms to ANSI/TIA/EIA-568-B.2-1, ISO/IEC 11801 2nd edition (2002) and CENELEC EN50173 (2002) for Category 6/Class E
Halogen free, flame retardent (HFFR) or PVC jacket

R3620020 - CAT6, U/UTP, 4 Pair, AWG23, Double Jacket, LSZH/PE, ECCS Armored Cable

Datasheet

CLASSix UTP Horizontal Armoured Cable - International

Enhanced performance cable for transmission of high speed data, digital and analogue voice and video (RGB) signals on LANs.
Supports Gigabit Ethernet (1000 Base-T)
Operates at bandwidth of 250MHz.
This cable well exceeds the requirements of ANSI/TIA-568-C.2, ISO/IEC 11801:2010
23 AWG Cable with HDPE Jacket over Armouring.
Armoured Cable with Inner Jacket as LSZH

R3722160/65 - CAT6 F/UTP, Horizontal Cable, PVC, 500/305m Reel

R3722060/65 - CAT6 F/UTP, Horizontal Cable, LSZH, 500/305m Reel

Datasheet

R3719060 - CAT6 F/UTP, Horizontal Cable, AWG23, LSZH, 332-3-22, Gray, 500mtr Reel

Datasheet

CLASSix F/UTP Horizontal Cable

Category 6 F/UTP 4 Pair screened cable
ISO11801 & TIA/EIA–568-C.2, UL Subject 444
Generic cabling systems. Including 10Base-T, 100Base–T, 1000Base-T, ATM & Token Ring, IEEE 802.3 af (PoE), IEEE 802.3 at (PoE+)

R3229000 - CLASSix UTP Patch Cable, PVC, 300m ReelReel

Datasheet

CLASSix UTP Patch Cable

100 Ohm, flexible, UTP patch cable
Four twisted pairs
High performance, designed for ATM 622 Mbps and Gigabit Ethernet
1000 Mbps and future high-speed applications
Specified up to 250 MHz
Conforms to ANSI/TIA/EIA-568-B.2-1, ISO/IEC 11801 2nd edition (2002) and CENELEC EN50173 (2002) for Category 6/Class E

R3257000 - CLASSix STP Patch Cable, PVC, 300m Reel

Datasheet

CLASSix STP Patch Cable

1100 ohm , foiled and shielded patch cable
Four individually foiled twisted pairs with an overall braid-shield
High performance, designed for ATM 622 Mbps, and Gigabit Ethernet 1000 Mbps applications
Conforms to ANSI/TIA/EIA - 568-B.2-1, ISO/IEC 11801 2nd edition (2002) and CENELEC EN50173 (2002) for Category 6/Class E
