SMARTen (CAT 6A)

CABLES

R3726020 - SMARTen U/FTP Un-Grounded Horizontal Cable, LSZH, 500m Reel

Datasheet

R3726120 - SMARTen U/FTP Un-Grounded Horizontal Cable, PVC, 500m Reel

Datasheet

SMARTen U/FTP Un-Grounded Horizontal Cable
  • 100 ohm, foiled and shielded horizontal cable
  • Four individually foiled twisted pairs with an overall braid-shield
  • High performance, designed to support protocols running at up to IEEE
  • 802.3an 10Gbps, 1000 Mbps, such as ATM 622 Mbps and Gigabit Ethernet
  • Specified up to 600 MHz
  • Conforms to Category 7 cables, specification as per IEC 61156-5 standard
  • Halogen-free, flame-retardant (HFFR) or PVC jacket


R3726030 - SMARTen U/FTP Horizontal Cable, LSZH, 500m Reel

Datasheet

R3726130 - SMARTen U/FTP Horizontal Cable, PVC, 500m Reel

Datasheet

SMARTen U/FTP Horizontal Cable
  • 100-ohm, screened horizontal cable
  • Four individually twisted pairs wrapped with a polyester-aluminum foil
  • High performance, supportable bandwidth up to 500 MHz according to IEEE 802.3an 10Gbps
  • Specified up to 500 MHz
  • Conforms to ANSI/TIA/EIA-568-C.2, ISO/IEC 11801 2.1 edition and CENELEC EN50173 (200x) latest drafts for Category 6A/CLASS EA
  • Backward compatible with Category 5e and Category 6 cabling standards
  • Low-smoke, Zero halogen (LSZH) or PVC jacket


R372202X/R372272X - SMARTen (CAT6A) U/FTP Horizontal Cable 23AWG Gray/Blue, LSZH,
500m/305m Reel

Datasheet


R371902X / R371972X - SMARTen (CAT6A) U/FTP Horizontal Cable 23AWG Gray/Blue, LSZH –
IEC 60332-3.22, 500m/305m Reel Reel

Datasheet


SMARTen U/FTP Horizontal Cable – LSZH – International
  • 100-ohm, screened horizontal cable
  • Four individually twisted pairs wrapped with a polyester-aluminum foil
  • High performance, supportable bandwidth up to 500 MHz according to IEEE 802.3an 10Gbps
  • Specified up to 500 MHz
  • Conforms to ANSI/TIA/EIA-568-C.2, ISO/IEC 11801 2.1 edition and CENELEC EN50173 (200x) latest drafts for Category 6A/CLASS EA
  • Backward compatible with Category 5e and Category 6 cabling standards
  •  Low-smoke, Zero halogen (LSZH) – IEC 60332-3.1 and IEC 60332-3.22

R3722880/85 - CAT6A Horizontal Cable, F/UTP, 23AWG, LSZH,
332-3-22, Gray, 500/305m Reel

Datasheet


SMARTen F/UTP LSZH 3.22 Horizontal Cable
  • Generic cabling systems.
  • Exceeds Category 6A cables specification per IEC 61156-5, Category 6 and Category 5e and tested up to 500 MHz
  • Very high performance, designed to support protocols running at up to 10Gbps
  • Cable flammability complies with IEC 60332-3-22, IEC 60332-1-2, IEC 60754-1/2, IEC 61034-1/2
  • RoHS compliant: 2011/65/EU
  • Applicable Standards: IEC 61156-5, 11801 Edition 2.0 & UL Subject to 444, ANSI/TIA – 568 - C.2
  • Including 10Base -T, 100Base -T 1000Base -T, ATM 10G & Token Ring
  • Low Smoke Zero Halogen (LSZH)
  • 100% factory tested

R371903X - CAT6A, S/FTP, Horizontal Cable, 23AWG, 25% Braiding, LSZH, 332-3-22, Gray, 500/305m Reel

Datasheet


SMARTen (Cat 6A) 23AWG S/FTP LSZH Horizontal Cable
  • Generic cabling systems.
  • Exceeds Category 6A cables specification per IEC 61156-5, Category 6 and Category 5e and tested up to 500 MHz
  • Very high performance, designed to support protocols running at up to 10Gbps
  • Cable flammability complies with IEC 60332-3-22(3A), IEC 60332-1
  • RoHS2: Directives 2011/65/EU, 2015/863/EU
  • Applicable Standards: IEC 61156-5, 11801 Edition 2.0 & UL Subject to 444, ANSI/TIA – 568 - C.2
  • Including 10Base -T, 100Base -T 1000Base -T, ATM 10G & Token Ring
  • Low Smoke Zero Halogen (LSZH)
  • 100% factory tested

R3722080/85 - CAT6A, U/UTP, Horizontal Cable, LSZH, Grey, 500/305m Reel

Datasheet


R3722780/85 - CAT6A, U/UTP, Horizontal Cable, LSZH, Blue, 500/305m Reel

Datasheet

SMARTen U/UTP or F/UTP LSZH 3.1 Horizontal Cablele
  • Generic cabling systems.
  • Standards - ISO 11801 Edition 2.0 & UL verified to ANSI/TIA – 568 - C.2
  • Including 10Base -T, 100Base -T 1000Base -T, ATM 10G & Token Ring
  • IEEE 802.3 af (PoE), IEEE 802.3 at (PoE+)


R3266000 - SMARTen U/FTP Un-Grounded Patch Cable, LSZH, 300m Reel

Datasheet

SMARTen U/FTP Un-Grounded Patch Cable
  • 100 ohm, ungrounded foiled patch cable
  • Four individually twisted pairs wrapped with a polyester-aluminum foil, aluminum face inside
  • High performance, supportable bandwidth up to 500 MHz according to IEEE802.3an 10Gbps
  • Specified up to 500 MHz
  • Conforms to ANSI/TIA/EIA-568-B.2-10, ISO/IEC 11801 2.1 edition and CENELEC EN50173 (200x) latest drafts for Category 6A/CLASS EA

R3268000 - SMARTen STP Patch Cable, LSZH, 300m Reel

Datasheet

SMARTen STP Patch Cable
  • 100 ohm, foiled and shielded patch cable
  • Four individually foiled twisted pairs with an overall braid-shield
  • High performance, supportable bandwidth up to 500 MHz according to IEEE 802.3an 10Gbps
  • Specified up to 500 MHz
  • Conforms to ANSI/TIA/EIA-568-B.2-10, ISO/IEC 11801 2.1 edition and CENELEC EN50173 (200x) latest drafts for Category 6A/CLASS EA
